Specifications:
-
Mic Inputs: 12 (8 × XLR, 4 × Combo XLR/JACK)
-
Line Inputs: 2 stereo channels (plus 2 × 6.5mm and 1 × 3.5mm jacks in parallel)
-
Master Output: 2 × L/R balanced XLR
-
Smart Outputs: 6 assignable balanced XLR
-
Internal Busses: 16
-
Stereo Monitor Output: 1 × TRS jack
-
Headphone Output: 1 × TRS jack
-
Screen: 7" HD touch screen
-
Control: 9 × high-resolution rotary encoders with LED indicators
-
Sample Frequency: 48kHz
-
AD/DA: 192kHz, 24-bit
-
DSP: 40-bit float, SHARC processor
-
Effects: Up to 8 assignable modules (reverb, modulation, delay, 31-band GEQ with RTA)
-
Digital I/O: AES/EBU output (XLR), S/PDIF input/output (RCA phono)
-
USB Interface: 2 (playback/recording, scene storage, system updates)
-
Network: Yes, via external WiFi module
-
Power: 100–120V / 200–240V ~ 50/60Hz
-
Dimensions (W × H × D): 585 × 290 × 305 mm
-
Net Weight: 6 kg
